Performance Characteristics
1.Wavelength 1310nm±20
2.Optical Output power range: 2~10mW
3.Two charging options-Solar & power adaptor, multiple choice for end user
4.Low current laser diode ensure low noise figure
5.Smart Digital display and control bring convenience in monitoring and handling
6.Optical Connector: SC/APC or FC/APC
7.AGC Fiber In function added. Fiber /RF IN, Fiber Out
8.Alumininum casing assure better heat sink and stable performance
9.Adopt C.M brand hybrid which use NXP transistors supply good linearity & flatness
Technical Specification
|
Number Item |
Unit |
Description |
Remark |
|
|
Optical Parameters |
||||
|
1 |
Wavelength |
nm |
1310±20 or 1550±10 |
|
|
2 |
Optical output power |
mW |
2~10 + 2~10 |
|
|
3 |
CNR |
dB |
＞51 |
|
|
4 |
CTB |
dB |
＞65 |
|
|
5 |
CSO |
dB |
＞60 |
|
|
RF Parameters |
||||
|
6 |
Frequency Range |
MHz |
45~862 |
|
|
7 |
Input Impedance |
Ω |
75 |
|
|
8 |
AGC Accuracy |
dB |
±5/±0.3 |
|
|
9 |
Input Return Loss |
dB |
＞16 |
|
|
10 |
Level adjustable range |
dB |
80±5 |
|
|
11 |
In-Band Flatness |
dB |
±0.50 |
|
|
12 |
Level test point |
dbuV |
Input level to laser -20dBuV |
|
|
General Parameter |
||||
|
13 |
Power Input Voltage |
VDC |
24 |
DC Power adaptor |
| Battery Socket |
VDC |
29~35 |
Solar |
|
| Charger Socket |
VDC |
29~35 |
Solar Battery back up |
|
|
14 |
Power Consumption |
A |
0.5 |
|
|
15 |
Dimensions |
mm |
210*150*60 |
|
|
16 |
Net weight |
KG |
1.5 |
|
